Own it Now, Pay Later
- Record up to 6K60 Video
- ZRAW and ProRes Recording
- 14 Stops of Dynamic Range
- Super 35 CMOS Sensor
- Canon EF Lens Mount
- Up to 12-Bit ProRes Recording
- 5G Wireless Support, Timecode Support
- Gigabit Ethernet for Data and Control
- Live Streaming via Ethernet
- iOS App for Control and Live Preview
Shoot professional high-definition cinema footage with the Z CAM E2-S6 Super 35 6K Cinema Camera with a Canon EF lens mount. The camera features a Super 35 sensor with 10-bit 4:2:2 colour support and nominal 14 stops of dynamic range, supports timecode, shoots up to 6K at up to 60 fps, DCI 4K up to 75 fps, 1080p up to 120 fps, and records data up to 300 Mb/s onto CFast 2.0 media.
It supports recording formats MOV and MP4 using ProRes raw for 12-bit recording and H.265 for 10-bit recording (H.264 supports 8-bit recording) when using the latest firmware update that allows the camera to record in both ZRAW and ProRes formats. The HDMI 2.0 port supports 4K60, 10-bit 4:2:0 video output. Audio is recorded in 24-bit 48 kHz using AAC or PCM (PCM for MOV format only) through its 3.5mm stereo jack or via a separately available XLR connector using its 5-pin LEMO port.
The E2-S6 can be controlled via serial ports, a 2.5mm LANC connector, a USB Type-C port, an Ethernet port, or by the Z Camera iOS app to control the camera via Wi-Fi and view a live image preview and configure settings. The camera can record time-lapse, and slow motion, and can even live stream via its Gigabit Ethernet port. You can also control it locally by the buttons along the side of the camera.
The E2-S6 can be powered by a separately available battery using the built-in L-series battery mount, or you can power the camera using a separately available power adapter using its 2-pin LEMO port. The camera also features a 12 VDC 2-pin LEMO power output to provide power to separately available accessories.
Firmware Update
4K Capture and Recording
- Unburdened by a recording time limit, you can record 6K at up to 60 fps for up to the limit of your recording media’s capacity
- CMOS sensor with 14 stops of dynamic range
- The camera supports ZRAW, ProRes raw, and REC. 709, Z-Log2, FLAT, and HLG
- H.265 (10-bit colour) internal recording on CFast 2.0 cards
- 4K60, 10-bit 4:2:2 video output through HDMI 2.0 is supported
- Full-metal housing for efficient heat dissipation
Interfaces and Expandability
- USB 3.0 Type-C for camera control and data transformation only
- Two serial ports for camera control
- Ethernet port for live view, control, and file transfer to a browser or a computer running Z CAM software
- LANC port for remote control including power on/off
iOS App
Camera Settings
- White balance: Auto, preset, manual (2300 to 7500K)
- Focus modes: MF, AF, CAF
- Image: Brightness, contrast, saturation, sharpness
- LUT: REC. 709, Z-Log2, FLAT, HLG
- Timecode: Current time, manual input
Camera Body
- Made from aluminium for strength and heat dissipation
- 2-pin LEMO 12 VDC power output
- Powers from optional 2-pin LEMO 12 VDC adapter or optional L-series batteries
